Titan Apex – 170-micron fluorescent printing vinyl in 5 colours, high-tack adhesive, micro-channel liner TITAN APEX Series — 170 µm fluorescent print vinyl in 5 colours (yellow, green, red, orange, pink)
- Free shipping from 300 €*
- Quick shipping in the whole world
- Certified technical service Quick support
- Custom advices & quotes Secured payment
TA.X-170
Fluo you notice before the engine even starts. The TITAN APEX series combines a 170 µm multi-layer PVC film, for high opacity and colour intensity, with a high-tack adhesive that holds on fairings and number plates.
- 5 fluorescent shades: yellow, green, red, orange and pink
- Easier dry application: the micro-channel liner lets the air out — no bubbles
- All ink technologies: eco-solvent, latex and UV
- Two lengths: 1370 mm × 25 m to try a shade, × 50 m for production runs
The go-to media for motocross, karting and motorsport graphics kits.
Combinations available
Check some of theses attributes to see what attribute combination is available
|
Ref: TAPX-170-25 |
Available now |
|
|
Ref: TAPX-170-50 |
Available now |
|
Ref: TAGX-170-25 |
Available now |
|
|
Ref: TAGX-170-50 |
Available now |
|
Ref: TAYX-170-25 |
Available now |
|
|
Ref: TAYX-170-50 |
Available now |
|
Ref: TARX-170-25 |
Available now |
|
|
Ref: TARX-170-50 |
Available now |
|
Ref: TAOX-170-25 |
Available now |
|
|
Ref: TAOX-170-50 |
Available now |
Accessories
More info
■ TITAN · Specialty Print Vinyl
Colour you see before you hear the engine.
Five printable fluo shades and an adhesive that grips plastic: everything you need for a graphics kit that gets noticed from the side of the track.
170 µm fluorescent print vinyl in 5 shades, high-tack adhesive, micro-channel liner. Rolls of 1370 mm × 25 or 50 m, eco-solvent, latex and UV.
5
fluo shades
170 µm
multi-layer PVC film
40 µm
high-tack adhesive
1370 mm
width · 25 or 50 m
3
ink technologies
■ Why APEX
Vivid fluo, forgiving application
◉
Fluo that really covers
The multi-layer PVC film delivers high opacity and colour density: the fluo stays vivid, even when printed and applied over coloured plastic.
↻
Bubble-free dry application
The structured kraft liner with micro-channels lets the air escape: squeegee, heat the curves, and the bubbles are gone.
Graphics kits, number plates, fairings: APEX is made for plastics on the move.
■ The range
Five shades, one construction
Same 170 µm film, same adhesive, same liner across the series. Only outdoor durability varies by colour — which is why a laminate makes sense.
| Shade | Reference | Outdoor* | |
|---|---|---|---|
| APEX Yellow | TAYX-170 | 12 months | |
| APEX Green | TAGX-170 | 12 months | |
| APEX Red | TARX-170 | 6 months | |
| APEX Orange | TAOX-170 | 6 months | |
| APEX Pink | TAPX-170 | 6 months |
* Unlaminated, Northern-European climate, vertical exposure. Lamination is recommended and can extend durability. Colour dots are indicative: fluorescent colours cannot be reproduced on screen.
■ Applications
Where APEX makes the difference
Motocross and enduro graphics kits
Fairings, mudguards, side panels: fluo underlines the lines of the bike.
Number plates and plate backgrounds
On a number plate, fluo means legibility in the race.
Support vans and team vehicles
Fluo accents on a wrap or lettering, matched to the bikes.
Karting, quads, jet skis
Any leisure vehicle that needs to be seen.
■ Application
Applying APEX right
1Let the print dry for 24 hours before laminating.
2Clean the surface with IPA (isopropyl alcohol).
3Apply dry, between 10 and 30 °C.
4Squeegee firmly.
5Use a heat gun to conform to curves.
■ Technical data
Key specifications
| Film | |
| Material | Premium multi-layer PVC, fluorescent |
| Thickness | 170 µm |
| Adhesive | |
| Type | Clear solvent acrylic, high-tack permanent |
| Thickness | 40 µm |
| Adhesion to steel, 24 h (FINAT FTM 1) | 37 N/25 mm |
| Adhesion to steel, 20 min | 30 N/25 mm |
| Liner | |
| Type | Structured lay-flat kraft, double PE-coated, micro-channels |
| Weight | 160 g/m² |
| Application | |
| Method | Dry |
| Application temperature | 10 to 30 °C |
| Service temperature | −5 to 50 °C |
| Printing and sizes | |
| Inks | Eco-solvent, solvent, latex, UV |
| Rolls | 1370 mm × 25 m · 1370 mm × 50 m |
| Durability | |
| Outdoor, unlaminated | 6 to 12 months depending on shade |
| Shelf life | 12 months (21 °C, 50% RH) |
Typical values from the TITAN technical data sheets (rev. 07.26). Titan product overview (PDF) ↓
■ Digital-sys
What Digital-sys adds
01The right choice before you print
Shade, roll length and laminate matched to your application.
02A trial before you commit
Samples on request to check the result on your printer.
03Support that speaks your language
Print settings, application, troubleshooting: a contact who knows the product.
04The whole workflow in one place
Printers, cutters, laminates and application tools.
✓ TITAN 12-month material warranty from invoice date (Fourbases BV), subject to proper storage.
Want to see the fluo for real?
Ask for a sample or a quote — we'll get back to you quickly.
Photos for illustration only.
