Secabo TPD7 PREMIUM automatic double plate heat press Secabo TPD7 PREMIUM automatic double plate heat press
Write your review
- Free shipping from 300 €*
- Quick shipping in the whole world
- Certified technical service Quick support
- Custom advices & quotes Secured payment
109.117.10
- Extremely high pressure of 12kN at 10bar (600g / cm2 or 1.2t)
- Automatic procedure of the pressing head
- Prepress function with adjustable prepress time
- Separately adjustable times for both base plates
- Storable sets of times and temperature
- Extremely high heating capacity and heat capacity of the heating plate, as well as professional heat distribution
- Includes sturdy base for ergonomic working height
- Includes 2 cross lasers for easy object positioning
Accessories
Data sheet
| Accessoires inclus | Chassis, plateau chauffant et plateau inférieur, Boitier de commande, câble d'alimentation, outils, notice d'utilisation |
| Poids Net | 32 kg |
| °C / °F Max | 225° |
| Puissance | 250 g/cm² |
| Fonctionnement | double plateau, pneumatique |
| Taille de plateau | 38 x 38 cm |
More info
TECHNICAL DATA
dimensions
90cm x 134cm x 84cm
working area
2 x 40cm x 50cm
scope of delivery
Transfer press, power cable, connection set for compressor, German-language operating instructions
pressure setting
setting of pneumatic pressure
max. downforce
600g/cm2 at 10bar g/cm²
max temperature
225 °C
maximum time preset
999 s
power supply
AC 230V / 50Hz - 60Hz, 2.5 kW
environment
+5°C - +35°C / 30% - 70% relative humidity
weight without packaging
110.00 kg
weight with package
139.39 kg
Brand
Secabo
